Carbon Steel C22.8 FLANGE EN1092-1 & DIN PN16-PN63 FLANGES TYPE13
THREADED FLANGE
1.CARBON STEEL C22.8 Flanges
Carbon Steel C22.8 Flanges, Carbon Steel C22.8 Slip On Flanges,
C.S. C22.8/S37.2Pipe Flanges, Carbon Steel C22.8 Blind Flanges,
ANSI B16.5 Carbon Steel C22.8 Flange, Carbon Steel C22.8 RTJ Flange
Supplier ,Carbon Steel C22.8 DIN 2.4602 Socket Weld Flanges, Carbon
steel C22.8 Threaded Flanges, Carbon Steel C22.8 Flanges, Carbon
Steel C22.8 WN RF Flanges Exporter, Carbon Steel C22.8 Blind
Flanges, C22.8 Weld Neck Flange Manufacturer in China.
2. CARBON STEEL C22.8 Flanges Specifications
| Specifications | ASTM EN DIN BS4504 |
| Size | 1/2″NB TO 60″NB |
| Standards | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10,
EN-1092, DIN, etc. |
| Class / Pressure | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40,
PN64 etc. |
| Standard | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges,
etc. |
3. Other Carbon Steel C22.8 Flanges we have
| Standard | Type | Class | Size |
| ASME B16.5 | WN/LWN/SO/Blind/Lap Joint | 150#-2500# | 1/2"-24" (Except Blind Flange 2500lb 1/2"-12") |
| SW flange | 150#-1500# | 1/2"-3" (Except 1500# 1/2"-2 1/2") |
| Threaded | 150#-900# | 1/2"-24" |
| 1500# 2500# | 1/2"-2 1/2" |
| ASME B16.47 Series A | WN/blind flange | 150# -900# | 22"-48" (Except 900# Size:26"-48") |
| ASME B16.47 Series B | WN/blind flange | 75#-300# | 26"-48" |
| 400# 600# 900# | 26"-36" |
| DIN2527 | Blind flange | PN6-PN100 | DN10-DN1000 |
| DIN2543 | SO flange | PN16 | DN10-DN1000 |
| DIN2544 | SO flange | PN25 | DN10-DN1000 |
| DIN2545 | SO flange | PN40 | DN10-DN500 |
| DIN2565 | Threaded flange with Neck | PN6 | DN6-DN200 |
| DIN2566 | Threaded flange with Neck | PN16 | DN6-DN150 |
| DIN2567 | Threaded flange with Neck | PN25 PN40 | DN6-DN150 |
| DIN2568 | Threaded flange with Neck | PN64 | DN10-DN150 |
| DIN2569 | Threaded flange with Neck | PN100 | DN10-DN150 |
| EN1092-1:2002 | Plate flange for welding/ loose plate flange with weld-on plate collar or for lapped pipe end/Blind Flange/WN flange | PN2.5-PN100 | DN10-DN4000 |
| JIS B2220 | Welding flange, lap joint flange, threaded flange | PN6-PN100 | DN10-DN1500 |
| BS4504 BS10 TableD/E | Plate Flange for welding/ WN flange/blank Flange | PN6-PN100 | DN10-DN1500 |
| Other Products | Anchor/swivel/girth/l ap joint/reducing/orifice |
Spectacle blind/paddle blind/ spacer ring/orifice plate/bleed ring |
Special Products: rings/ forgings/disc/shaft sleeves |
| Sealing Surface | RF FF RTJ TF GF LF LM |
| Flange Face Finish | Stock finish/spiral serrated/ concentric serrated/smooth finish (Ra 3.2 and 6.3 micrometers) |
| 125-250 AARH(it is called smooth finish) |
| 250-500 AARH(it is called stock finish) |
| Coating | Vanish, yellow paint, anti-rust oil, galvanizing etc |
| Materierial | Stainless Steel | |
| Stainless Steel | ASTM/ASME A/SA182 F304,304L,304H,309H,310H, 316,316H,316L,316LN, |
| 317,317L,321,321H,347,347H |
| |
| Carbon steel | ASTM /ASME A/SA105(N) |
| Low Temp Carbon Steel | ASTM/ASME A/SA350 LF2 |
| High Yield Carbon Steel | ASTM/ASME A/SA694 F52,F56 F60, F65, F70 |
| |
4. Type of Carbon steel C22.8 Flanges
| Carbon Steel C22.8 Flanges | Weld Neck Flange (TYPE 11 WN FLANGE)
Slip On Flange (TYPE12 SO Flange)
Plate Flange (TYPE01 PL Flange)
Blind Flange (TYPE05 BL Flange) Threaded Flange (TYPE13 THD FLANGE) Loose Flange (TYPE02) |
5. About C22.8 Flanges
Carbon Steel C22.8 Pipe Flanges Chemical Composition
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| C22.8 | 0.18-0.23 | 0.3-0.9 | 0.4 max | 0.025 max | | | | 2.00 – 6.00 | | 0.015 max |
6. Carbon Steel Flanges Test Certificates
We provide Manufacturer TC (Test Certificate) in accordance to EN
10204/3.1B, Raw Materials Certificate, 100% Radiography Test
Report, Third Party Inspection Report. We also provide Standard
certificates like EN 10204 3.1 and additional requirement like.
NACE MR 01075. FERRIT CONTENT as per norms if requested by clients.
• EN 10204/3.1B,
• Raw Materials Certificate
• 100% Radiography Test Report
• Third Party Inspection Report, etc
ASTM, ASME Hastelloy C22.8 Flanges Value Added Services
Material Testing:
We at Ganpat Industrial Corporation ensure that all our materials
go through strict quality tests before dispatching them to our
clients.
• Mechanical Testing Such as Tensile of Area
• Hardness Test
• Chemical Analysis – Spectro Analysis
• Positive Material Identification – PMI Testing
• Flattening Test
• Micro and MacroTest
• Pitting Resistance Test
• Flaring Test
• Intergranular Corrosion (IGC) Test
Documentation
• Commercial Invoice which includes HS Code
• Packing List including net weight and gross weight, number of
boxes, Marks and Numbers
• Certificate of Origin legalized/attested by Chamber of Commerce
or Embassy
• Fumigation Certificates
• Raw Material Test Reports
• Material Traceability Records
• Quality Assurance Plan (QAP)
• Heat Treatment Charts
• Test Certificates certifying NACE MR0103, NACE MR0175
• Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204
3.2
• Guarantee Letter
• NABL approved Laboratory Test Reports
• Welding Procedure Specification/Procedure Qualification Record,
WPS/PQR
• Form A for the purposes of the Generalized System of Preferences
(GSP)
7. Carbon steel C22.8 Flanges Packaging
Carbon Steel C22.8 Flanges are widely used in various industries
including petrochemical, oil and gas, power generation, bulk liquid
transportation, chemicals, pharmaceuticals, pulp and paper
manufacturing, textiles and others. All our Carbon Steel C22.8
Flange are manufactured in accordance with international standards.
Carbon Steel C22.8 Pipe Flange are packaged to ensure that there is
no damage during transit. In case of exports, standard export
packaging is done in wooden cases. Carbon Steel C22.8 Plate Flanges
are marked with Grade, Lot No, Size, Degree and our trade mark. On
special requests we can also, make custom marking on Carbon Steel
C22.8 Flanges.
Product Description
| Material | F304, 304L, F316, F316L, F321, 316Ti, 317L, 347, F5, F9, F11, F22,
LF2, A105, 1.4541, 1.4571, 1.4404, 1.4307 and P250GH. |
| Size | from 1/2"-84" |
| Standard | ANSI, DIN, JIS, BS, SH, BS4504, EN1092-1, BS3293 and other
standards. |
| type | WN,SO,BL,SW,LJ,TH, |
| packing | plywood case, pallet or according to customers’ requirements |
| certificate | TUV&ABS, ISO9001:2000, Pressure Equipment Directive PED
97/23/EC, and BV and AD2000-Merkblatt WO |
| Sealing surface | FF ,RF, LJ, FM ,R.T.J and so on |
Why Choose Us
1. One-Stop Service,One Single Source.
2. No MOQ.
3. Best quality,competitive price
4. Fast Reply.
5. On-Time Delivery
6. Professional sales and technical team .
